Obeya assembly instructions
1. Attach coat hook before installing full wall panel on to structure.
2. Fasten coat hook to full wall panel using (2) 1/4-20 x 30mm bolts
through pre bored holes in panel from back side into 1/4-20 insert nuts
in the back of the coat hook
Coat hook
Full wall panel
w/ pre installed
hanging clips
1/4-20 Bolt
Full wall panel
(back side)
Coat hook
