AB23PH Bench pH Meter EN-7
2.2 Installing the power adapter
Insert the proper adapter clip into the power adapter slot.
2.3 Connect the pH electrodes
There are 3 sockets for electrode. “pH/mV” socket (BNC); “Temp.” Socket (Cinch) and
“Ref.” Socket (2mm banana).
For 2-in-1 pH electrode, you only need to connect to the BNC socket, while for other
electrodes, you need to connect to the BNC and Cinch socket.
Note: REF socket is for separate reference electrode.
