OHAUS NV212 - Page 41

CHAPTER 5 PARTS LISTS & DIAGRAMS
Navigator Series Service Manual 35 Ohaus Corporation www.ohaus.com
TABLE 5-1 HOUSING & INTERNAL PARTS
Drawing
Item
Description
1
Pan
2
Pan Support
3a
Function Label, LCD
3b
Function Label, LED
4
Housing, Top, No Labels
5
Housing, Bottom (Shipping Lock)
6
Load Cell
7a
Main PCB, LCD
7b
Main PCB, LED
8a
LCD Display and Backlight
8b
LED Display
9
Cable Kit (Power Adapter Jack Cable shown)
10
Level Bubble and Light Guide
11
Battery Cover
12
Interface Cover
13
Battery Connection Spring
14
Feet
20
Hardware Kit
Not shown
Power Adapter (no plugs)
Not shown
Power Adapter Plug Set
Not shown
Packaging, Insert
Not shown
Box, Shipping
