EN-2 SD SERIES BENCH SCALE
Introduction
This manual covers operation for the Ohaus SD Series Bench Scales.
Unpacking
SD Series Bench Scale is shipped with the following components:
• Indicator • AC Power Adapter
• Scale Base • This Instruction Manual
• Mounting Brackets • Warranty Card
Leveling Scale Platform
The Scale Base should be placed on a level, stable surface before operation.
Models SD75L and SD200L are equipped with adjustable leveling feet. Adjust the
four leveling feet under the platform to level it.
Power Options
AC Adapter Operation
• The AC Adapter (included) may be used to power the system when battery
power is not available.
• Check that the AC input power as marked on the Adapter matches the
available power source.
• Connect the round plug of the AC Adapter to the power input jack at the side of
the Indicator housing. See Figure 1.
• Plug the AC Adapter into an AC power outlet.
Figure 1. Connecting Adapter Plug to Indicator.
