Appendix C Maintenance Manual for Second Tray unit
43984801TH Rev.1
156 /
Oki Data CONFIDENTIAL
④
③
⑥
⑤
⑤
⑧
❾
⑦
⑥
Cable
Positions of Lever-Paper-End and Sensor
The top of the Lever-Paper-End should be in
the groove of the sensor.
Sensor
Lever-Paper-End
