43984801TH Rev.1
63 /
Oki Data CONFIDENTIAL
3. Parts replacement
Claw D
❿
⑪
⓬
⑪
Hopping-shaft
Plate-Base-Assy
(9) Remove the 2 of E ring
⑪
, Slide Hopping-shaft by the arrow direction and remove Gear-Assy-Clutch
⓬.
(10
) Installing is performed by the inverse procedure with removing.
(Note on removing / installing)
1. B
eware of not to touch the DC motor inattentively (Do not rotate motor).
・
Remove Feed-Roller / Clutch.
(8) P
ress Claw D by the arrow direction an d remove Feed-Roller-NO
❿
.
To Next Page
