Control Codes: HP PCL5e • 13
Control Codes
HP PCL5e
HP PCL5e Control Codes
ASCII Hexadecimal Decimal Function
BS 08 08 Back Space
HT 09 09 Horizontal Tab
LF 0A 10 Line Feed
FF 0C 12 Form Feed
CR 0D 13 Carriage Return
SO 0E 14 Select Secondary Font
SI 0F 15 Select Primary Font
ESC % # A 1B 25 # 41 27 37 # 65 Enter PCL Mode
ESC % # B 1B 25 # 42 27 37 # 66 Enter HP-GL/2 Mode
