B6500 User’s Guide> 11
With Optional Accessories
10 Power cord
connector
For connecting the power cord.
11 Parallel
connector
For connecting the parallel cable.
12 Network
connector
For connecting the network cable when connecting this
printer to the network for use.
13 USB connector For connecting the USB cable.
14 Serial connector For connecting the serial cable.
No. Name Description
1 Offset catch tray
(optional)
Allows you to stagger the output position for each
print job (offset output).
2Cover D
(optional)
Open this when paper is jammed inside the offset
catch tray.
3Rear tray
(optional)
Use this tray if you want to reduce curling of paper
when printing heavyweight paper. Print jobs are
output here with the printed side facing up.
4 Duplex unit
(Cover C)
Enables 2 sided printing. When paper is jammed
inside the duplex unit, it is described as cover C.
No. Name Description
1
2
4
5
3
6
7
