B6500 User’s Guide> 48
LCD Display
The LCD display shows status and error messages that inform you
of the current status of the printer, and also displays menus,
submenus, and printer settings when you are in the menu system.
The display contains two lines of text, each with a maximum of
sixteen characters.
<On-Line>
button/indicator
Press to enter the off-line status. When in the off-line
status, the machine cannot receive data or process
printing. Press again to exit the off-line status and
enter the on-line status (where the machine can
receive data from the computer).
<CANCEL>
button
Press to cancel printing.
Press to exit the menu mode.
<Select> button Press to activate the displayed setting. When you are
changing the candidate values, pressing the Select
button runs the currently displayed activity or saves
the currently displayed candidate.
<> <>
<> <>
buttons
Press these to move to the required menu, item and
candidate value on the display.
Name Description
Current printer status
Printing
USB
PCL
(USB, Net, LPD, etc.)
Port Receiving Data
Language
(PCL, PS, etc.)
To Next Page
Loading...
