- 80 -
5. Management / Setting the Printer
• SIDM Setup
• IBM PPR Setup
Font Pitch 10.00 CPI Sets the width of the PCL default font. Available range:
0.44 to 99.99 CPI. (0.01 CPI increments)
Font Height 12.00 point Sets the height of the PCL default font. The height is
displayed to two decimal points (at 0.25 point intervals).
Symbol Set PC-8 Selects a PCL symbol set.
A4 Print Width 78 column Sets the number of columns for automatic line feed on
A4 paper for PCL. The number of columns is based on
when the font pitch is 10CPI and the Auto CR/LF mode is
set to off.
White Page Skip Off Sets whether to eject a blank page when an FF
command (0CH) is received in PCL.
CR Function CR Sets the printer operation when a CR code is received in
PCL.
LF Function LF Sets the printer operation when a LF code is received in
PCL.
Print Margin Normal Sets the non-printable area of page.
True Black Off PCL: Sets whether to use composite black (CMYK
mixed) or true black (K only) for the 100% black area of
an image.
Pen Width Adjust On When the minimum line width is specified in PCL, a 1 dot
line may look like a broken line. This mode adjusts fine
lines so that they look like solid lines.
Tray ID# MPTray 4 Sets a number of MP tray for the paper feed destination
command (ESC&l#H) in PCL5 emulation.
Tray1 1 Sets a number of tray 1 for the paper feed destination
command (ESC&l#H) in PCL5 emulation.
Tray2 5 Sets a number of tray 2 for the paper feed destination
command (ESC&l#H) in PCL5 emulation.
This menu is displayed only when the tray 2 is installed.
Tray3 20 Sets a number of tray 2 for the paper feed destination
command (ESC&l#H) in PCL5 emulation.
This menu is displayed only when the tray 3 is installed.
Tray4 21 Sets a number of tray 2 for the paper feed destination
command (ESC&l#H) in PCL5 emulation.
This menu is displayed only when the tray 4 is installed.
Tray5 22 Sets a number of tray 2 for the paper feed destination
command (ESC&l#H) in PCL5 emulation.
This menu is displayed only when the tray 5 is installed.
Item Factory
Default
Description
Item Factory Default Description
SIDM Manual ID# 2 Sets up Pn specified in MANUAL by MANUAL-1 ID
No.FX/PPR Emu in CSF control command (ESC EM
Pn).
SIDM Manual2 ID# 3 Sets up Pn specified in MANUAL by MANUAL-2 ID
No.FX/PPR Emu in CSF control command (ESC EM
Pn).
SIDM MP Tray ID# 4 Sets up Pn specified TRAYO (MP Tray) by MP Tray ID
No.FX/PPR Emu in CSF control command (ESC EM
Pn).
SIDM Tray1 ID# 1 Sets up Pn specified TRAY 1 by Tray 1 ID No.FX/ PPR
Emu in CSF control command (ESC EM Pn).
SIDM Tray2 ID# 5 Sets up Pn specified TRAY 2 by Tray 2 ID No.FX/ PPR
Emu in CSF control command (ESC EM Pn).
SIDM Tray3 ID# 6 Sets up Pn specified TRAY 3 by Tray 3 ID No.FX/ PPR
Emu in CSF control command (ESC EM Pn).
SIDM Tray4 ID# 7 Sets up Pn specified TRAY 2 by Tray 2 ID No.FX/ PPR
Emu in CSF control command (ESC EM Pn).
SIDM Tray5 ID# 8 Sets up Pn specified TRAY 2 by Tray 2 ID No.FX/ PPR
Emu in CSF control command (ESC EM Pn).
Item Factory Default Description
Character Pitch 10 CPI Specifies character pitches in IBM PPR emulation.
Font Condense 12 CPI to 20 CPI Specifies 12CPI pitches for Condense Mode.
Character Set SET-2 Specifies a character set.
Symbol Set IBM-437 Specifies a symbol set.
Letter O Style Disable Specifies the style that replaces 9BH with letter o and
9DH with a zero.
Zero Character Normal Sets the zero to be slashed or unslashed.
Line Pitch 6 LPI Specifies the line spacing.
White Page Skip Off Selects whether to print blank pages.
CR Function CR Selects a carriage return from [CR] or [CR+LF].
LF Function LF Selects a line feed from [LF] or [LF+CR].
Line Length 80 Column Specifies the number of characters per line.
Form Length 11.7 inch or 11 inch *
1
Specifies the length of paper.
TOF Position 0.0 inch Specifies the distance from the top edge of paper.
Left Margin 0.0 inch Specifies the distance from the left edge of paper so that
the print starting point shifts to the right horizontally.
