Oki C910 Service Manual

Oki Data CONFIDENTIAL
44043511TH Rev.2
143 /
Table 5-1-2 Paper Size Detection, Various Paper Types and Bits
No.
Top of the
Display
1 2 3 4
Detail Display Detail Display Detail Display Detail Display
34 FIN S01_S02_
S03_S04
Uper Cover
Sns [PI23]
H:OPEN L:
CLOSE
Front door Sns
[PI22]
H:OPEN L:
CLOSE
Front door SW
[MS2]
H:OPEN L:
CLOSE
Joint SW [MS1] H:OPEN
L:CLOSE
35 FIN S05_S06_
S07_S08
Bookbind-
ing position
Sns[PI10]
H:Paper
present
L:Paper
absent
Processing
tray Sns [PI6]
H:Paper
present
L:Paper
absent
Entrance Sns
[PI1]
H:Paper
present
L:Paper
absent
Punch timing
Sns
H:Paper
present
L:Paper
absent
36 FIN S09_S10_
S11_S12
Bookbinding
tray paper Sns
[PI13]
H:Paper
present
L:Paper
absent
Bookbinding
home position
Sns [PI11]
H:Home
position
L:Except in
the home
position
Bookbinding
roller home
position Sns
[PI12]
H:Home
position
L:Except in
the home
position
Front matching
home position
Sns [PI4]
H:Home
position
L:Except in
the home
position
37 FIN S13_S14_
S15_S16
Rear matching
home position
Sns [PI5]
H:Home
position
L:Except in
the home
position
Belt home posi-
tion outlet Sns
[PI7]
H:Home
position
L:Except in
the home
position
Feed roller
home position
Sns[PI3]
H:Home
position
L:Except in
the home
position
Paddle home
position [PI2]
H:Home
position
L:Except in
the home
position
38 FIN S17_S18_
S19_S20
Staple / fold
motor clock
[PI14]
H/L:Clock Self prime Sns
[PI21]
H:Start
staple de-
tection
L:Staple
absent
Staple Sns
[PI20]
H:Staple
absent
L:Staple
present
Stapler safty
SW [MS3]
H:Not to
drive
L:Drive
39 FIN S21_S22_
S23_S24
Staple home
position
Sns[PI19]
H:Home
position
L:Except in
the home
position
Stapler slide
home position
Sns [PI18]
H:Home
position
L:Except in
the home
position
Stapler connect
signal
Hconnected
Luncon-
nected
Stack tray
lift motor
clock[PI17]
H/L:Clock
40 FIN S25_S26_
S27_S28
Lower stack
tray Sns [PI16]
H:Lower
position
L:Except in
the lower
position
Upper stack
tray Sns [PI15]
H:Upper
position
L:Except in
the upper
position
Interlevel stack
tray Sns [PI24]
H:Interlevel
detection
L:Interlevel
undetection
Paper stack
tray Sns [PI9]
H:Paper de-
tect position
L:Except in
the paper
detect posi-
tion
41 FIN S29_S30_
S31_S32
Stack tray
paper Sns [PI8]
H:Paper
present
L:Paper
absent
Punch connect
signal
Hconnected
Luncon-
nected
42 INV IN_OUT_
EXIT_COV
Entrance Sns
[FP1]
H:ON
L:OFF
Outlet Sns
[FP2]
H:ON
L:OFF
PU®Inverter
Exit Sns Signal
H:ON
L:OFF
Cover open
SW [FMS1]
H:Open
L:Close
43 INV REMAIN_
JOINT
Lower
Sns[FP3]
H:ON
L:OFF
Inverter con-
nected Sns
[FP4]
H:ON
L:OFF
PU®Inverter
CNT2 Signal
H:ON
L:OFF
44 HALL BELT_ DT-
BOX_DCT
Belt Hole IC H:ON
L:OFF
Waste Toner
Box Hole IC
H:ON
L:OFF
Waste Toner
Hole IC
H:ON
L:OFF
No. Paper 1 2 3 4
0 No cassette H H H H
1 B5-L L H H H
2 Legal 13-S H L H H
3 B5-S L L H H
4 A4-L H H L H
5 Letter-L L H L H
6 A5-S H L L H
7 A4-S L L L H
8 B4-S H H H L
9 A3-S L H H L
A Legal 14-S H L H L
B Executive-S L L H L
C A3nobi-S H H L L
D Ledger-S L H L L
E A6-S H L L L
F Letter-S L L L L
