Oki Data CONFIDENTIAL

44043511TH Rev.2

68 /

Connect Power Supply Cord

Note! Be certain the power switch is placed in the OFF (O) position.

(2) Insert the power supply cord into the receptacle socket.

(1) Plug the power supply cord in the printer.

The connection of grounding wire is absolute.

OFF

Power supply

cord

May cause an electric shock.
