OkiLAN 8200e Network User’s Guide
199
Name (Cprinter:root) : root
331 Password required.
Password:<CR>
230 User Logged in
ftp>
2. Move to the preferable logical directory using the cd command.
Example
Moving to the lp directory and confirming the current directory.
ftp> cd /lp
250 Command OK.
ftp> pwd
257 ”/lp” is current directory
ftp>
3. Configure the transfer mode.
There are two types of transfer mode:
– BINARY mode, in which the file contents are output as it is and
– ASCII mode, which converts the LF code to the CR+LF code.
If a binary file converted by the printer driver is transferred, the
transfer mode has to be BINARY mode.
Example
Changing transfer mode to binary mode and verifying the current
mode
ftp> type binary
200 Type set to I.
NOTE
The network card logical directory structure is hierarchal. You
must now move to the logical directory since it is not possible
to output print data to the root directory.
To Next Page
