44473001TH Rev.1

105 /

Oki Data CONFIDENTIAL

4.REPLACEMENT OF PARTS

4.2.7.9 Cable (ADF-Reg SNS)

(1) Remove the cable

①

4.2.7.10 Frame-assy-OP

(1) Remove the eight claws to remove the frame-assy-OP

①

(2) Remove the screw

②

to remove FG cable

③

View A

Claws
