Oki ES7470 series User Manual

- 13 -
Table of contents
1
2
4
5
6
3
Table of contents
About the Product Warranty ....2
Emergency rst aid ..................3
Manufacturer ...........................3
Importer to the EU/Authorized
representative .........................3
Environmental information ......3
For Your Safety ........................4
When using the machine ......................6
During maintenance or inspection ..........8
When handling supplies .......................9
About the Manuals .................10
About This Manual .................12
Notation used in this manual ............ 12
Terms in this document ................... 12
Symbols in this document ................ 12
Illustrations in this document ........... 12
1 Checking the Product ......15
Name and Function of Each
Part .......................................16
Machine ......................................... 16
Components and Options ................. 18
Operator Panel ............................... 19
Adjusting the angle of the control
panel ............................................... 20
About the Operator Panel ......21
Description of the Touch Panel
Display .......................................... 21
Message displayed ............................. 21
Touch buttons ................................... 22
Adjusting the contrast of the touch
panel ............................................... 22
Simultaneous Functions
(Multi-operational) .......................... 22
Setting letters ................................ 23
Checking the Product ............. 24
2 Installing the Machine ....25
Installation Conditions...........26
Unpacking and Installing the
Machine .................................29
Installing Additional Tray
Units ......................................33
Setting Up the Printer for Windows .... 37
Conguring the options ......................37
Setting the department code ..............38
Copying the PPD le for Windows ........40
Setting Up the Printer for Mac OS X ... 40
Conguring the printer on Mac OS X ...40
Connecting the Cables ...........44
Connecting the Network Cables ........ 44
Connecting the USB cable ................ 44
Connecting to the telephone line ....... 45
3 Turning Power ON/OFF ...48
Precautions about the Power
Supply ...................................49
Turning Power ON .................50
Power switch is OFF ........................ 50
Power switch is ON.......................... 50
Turning Power OFF ................51
Economizing power
consumption (energy saver
mode) when not using the
device ....................................52

Oki ES7470 series Specifications

General

Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Modem Speed	33.6 kbps
Functions	Print, Copy, Scan, Fax
Duplex Printing	Yes
Maximum Paper Size	A3
Processor Speed	800 MHz
Print Resolution	1200 x 1200 dpi
Scan Type	Color Flatbed Scanner
Fax Transmission Speed	Approx. 3 seconds per page
Connectivity	USB 2.0, Ethernet 10/100/1000 Base-TX
Mobile Printing	AirPrint, Google Cloud Print
Operating System Compatibility	Windows, Mac OS
