11Read Me First
Switching Paper Paths
To switch from continuous-forms to single-sheet feed:
1. Tear off any printed pages.
2. Press PARK.
3. Move the paper separator to the single-sheet feed position.
4. Place the wire feed guide in the paper separator.
5. Move the paper lever to the position marked “TOP.
6. Place a sheet of paper in the paper separator.
To switch from single-sheet feed to continuous forms:
1. Press FF/LOAD to remove the single-sheet paper.
2. Lower the paper separator into the continuous-forms
position and swing the wire feed guide over onto the
pull-up roller.
3. Move the paper lever to the position marked “REAR” or
“BOT, as appropriate.
4. Load continuous-form paper, then press FF/LOAD.
Setting the Printhead Gap
The printhead gap is the distance between the printhead and
the platen. To adjust the gap, open the access cover and move
the blue lever () to the recommended setting from the table
below.
Note: It is recommended that the printer be switched off
prior to removing the access cover.
Media Setting Media Setting
45-75g/m² paper 1 2-part form (w/carbon) 3-4
75-90g/m² bond paper 2 3-part form (w/carbon) 4-5
Labels 3-4 4-part form (w/carbon) 5
Envelopes 5
3320rmf3.pm6 13/03/96, 16:0811
