(2) Line Feed Motor
Resistance of each coil should be about 10.4Ω.
Signal Connector pin number
LF1
LF2
LF3
LF4
CN4
LF
motor
1
2
3
4
(3) Space Motor
Resistance of each coil should be about 22.4Ω.
Signal Connector pin number
SP-U
SP-V
SP-W
SPA
SPB
SPTEMP
0V
CN2
SP
Motor
sensor
φA
φB
Thermistor
(5KΩ at 25°C)
18
17
6
22
21
11
20
