42113901TH01 Rev.3 6 /
Oki Data CONFIDENTIAL
1. CONFIGURATION
1.1 Standard Printer Configuration
This printer consists of the following assemblies:
Figure 1-1 Configuration
Upper cover
Access cover assy
Platen knob
Sheet guide assy
Control board
Power supply board
Transformer assy
Pull-up roller assy
Main chassis assy
Operation panel assy
