OKM Rover UC - Technical Specifications; Telescopic Probe Specifications; Wireless Data Transfer Specifications

2 TECHNICAL SPECIFICATIONS
The technical specifications are medial values. During operation slight variations are possible.
2.1 TELESCOPIC PROBE
Dimensions (L x W x H) 670 – 1380 x 65 x 80 mm
Weight 0.5 kg
Input Voltage (max) 5 V DC, 2 A
Charge time 3 h @ 10 – 30 °C
Operating time approx. 48 h
CPU Cortex-M0+, 24 MHz
Display LCD, 80 x 160 Pixel
Sample rate 240 values / second
Measurement resolution 15 bit
Interconnect Bluetooth 5.2, max. distance 8 m
Operating temperature -5 – 60 °C
Storage temperature -10 – 70 °C
Air humidity 5 % – 75 %
Technology GST, EMSR
Sensor technology SCMI-15-D
Compass Yes
Pedometer Yes
Waterproof No
2.2 WIRELESS DATA TRANSFER
Technology Bluetooth 5.2
Frequency range 2.4 – 2.4835 GHz
Maximum transfer rate 1 Mbps
Receiving sensitivity -85 dBm
Maximum range approx. 8 m (Line of Sight)
7 / 34
TECHNICAL SPECIFICATIONS
