MAESTRO PRO INVERTER
ENGLISH
EN - 15
.... thatthexingbracketsarewellanchoredtothewall,
.... that the installation site has been prepared for electrical connection and condensation discharge (if
necessary),
it is possible to hook the air conditioner.
Work as follows:
a. Applyadhesivetape(A)tohavereferencestothehookingpointsoftheunit(g.25).
The tape can be removed once the unit has been hooked to the wall.
b. Raisetheairconditionerholdingitbythesidesofthelowerbaseandhookittothebrackets(L)(g.26).
Slightly tilt the lower part of the appliance towards yourself to ease the operation.
• To make the electrical connection and fasten the drainpipe, place a wedge between the air con-
ditioner and the wall (see g. 27).
• When you have nished, inspect carefully to make sure there are no ssures at the back of the
air conditioner (the insulating gasket must t rmly against the wall) particularly in the zone
where air enters and leaves the machine.
2.4.6 - Electric hook-up
Theapplianceisttedwithapowercordwithplug(BTYPENEMA5-15/CS22.2).
If the socket is in proximity to the appliance, simply plug it in.
Before connecting the conditioner, ensure that:
• The power supply voltage and frequency values comply with those indicated
on the data plate of the appliance.
• The power supply line is tted with an efcient earth connection that is ap-
propriately sized for the maximum absorption of the conditioner (minimum
cross-section of the cable must be 14 AWG).
• The appliance is powered exclusively through a socket that is compatible with
the plug supplied.
Any replacement of the power cable must be carried out solely by authorized
technical support or by similarly qualied personnel.
On the power supply line of the appliance there must be an adequate omnipolar
disconnection device that complies with the national installation regulations.
It is, however, necessary to check that the electrical power supply is equipped
with efcient earthing and with adequate protections against overloading and/
or short circuits (a type 15 AT delayed fuse or other devices with equivalent
functions are recommended).
Use a single outlet circuit only.
