MODEL 709 MINI SUPREME BREAD SLICER
0709S20029-3
The actuating flag should trip the lower limit switch when the cradle handle is at the top
of its travel. The upper limit switch should be actuated when the cradle handle is at the
bottom of its travel. The tripping point of a limit switch can be detected by an internal
clicking sound made by the switch. Before attempting to adjust the flag or switches
make sure that the switch levers have not been bent, or, the switch otherwise damaged,
or, that the actuating flag is not just loose on the shaft.
Should switch adjustment be necessary they should be adjusted so that they are tripped
during normal movement of the cradle handle just before either end of the handle’s
travel.
To adjust either of the limit switches or the actuating flag, use the following procedure.
Loosen the set screw in the actuating flag allowing it to rotate easily on the shaft. With
the cradle handle in its upper most position, loosen both of the screws securing the
lower limit switch. Once loosened move the switch until it is approximately in the center
of its travel and re-tighten the switch. Move the loosened actuating flag into the lower
switch lever until you hear it trip. Tighten the flag’s set screw. Re-check the operation of
the switch using the cradle handle. It should function as described above.
Should the upper limit switch need adjustment, (after setting the lower switch as
described above), loosen the two screws which secure it in position and with the cradle
handle in its lowest position move the switch into the flag until you hear it trip. Re-tighten
the screws and re-check the switch operation as before.
