MODEL 709 MINI SUPREME BREAD SLICER
10/15
rev. 11/2010 0709S20044
B-NO. PART DISCRIPTION PART NO. QTY
101 SPACER BEARING 0709-0009 2
102A LEVER 0709-0011-0023 1
102B GEAR-SPUR 68T 0709-0011-0033 1
102C STUD-PIVOT 0709-0011-0013 1
105A ARM-PUSHER 0709-0046-0023 2
105B ACTUATOR-SWITCH 0709-0046-0034 1
105C SHAFT 0709-0046-0073 1
105D GEAR 44T 0709-0046-0093 1
105E BLOCK PIVOT 0709-0046-0083 2
105F BEARING-SINT BRZ 5254-0322 2
105G COLLAR 0709-0046-0063 1
106 ANCHOR BRACKET 0709-0079 1
107 BEARING-PILLOW BLK 5251-8090 2
109 KNOB-BALL 5911-7001 1
110 SPRING-EXTENSION 7022-4113 1
202 ROCKER 0709-0008 1
