MODEL 709 MINI SUPREME BREAD SLICER
0709S20030-1
MAINTENANCE
WARNING
ALWAYS
UNPLUG THE SLICER BEFORE PERFORMING ANY TYPE
OF MAINTENANCE TASK.
• Removing Blade Frames:
Remove the top and front covers by removing the four screws which holds each in place.
The table lip should be removed with the top cover.
NOTE
A TABLE LIP IS ATTACHED BETWEEN THE TOP COVER AND THE
INFEED TABLE BY FRICTION, A SLIGHT PULL MAY BE REQUIRED
TO DISLODGE IT.
Next remove the lower screw from the holddown pivot block on each side of the
machine, also loosen the upper screws of the pivot blocks but do not remove them.
When this has been done you will be able to pivot the holddown out of the knives to
allow removal of the blade frames.
Remove the upper blade frame by removing the shoulder screw from the foot of the
blade frame, (the blade frame is connected to the rocker by means of a plastic link at the
“Foot” of the blade frame). Once the shoulder screw and link have been removed the
blade frame can be slid forward and removed from the tracks and from the machine.
WARNING
THE BLADES ARE EXTREMELY SHARP. ALWAYS
HANDLE THE
BLADE FRAMES WITH CARE.
To remove the lower blade frame, (see note below), you must first remove the four
screws from the infeed table. While this table does not have to be removed from the
machine it must be moved down out of the way to allow removal of the lower blade
frame.
NOTE
REMOVAL OF THE LOWER BLADE FRAME IS NOT
REQUIRED TO
CHANGE ITS BLADES.
