MODEL 709 MINI SUPREME BREAD SLICER
0709S20029-1
ADJUSTMENTS
WARNING
ALWAYS
UNPLUG THE SLICER WHEN ADJUSTING OR SERVICING.
• Slices Vary In Thickness:
NOTE
IN ONLY THREE SITUATIONS SHOULD IT BECOME NECESSARY TO
ADJUST THE BLADE FRAMES FOR A VARIANCE IN SLICE THICKNESS.
1. IF THE BLADE FRAME GUIDE BARS BECOME LOOSE ALLOWING
THE FRAME TO MOVE.
2. IF THE BLADE FRAMES WERE REMOVED FROM THE MACHINE
AND REPLACED IN OPPOSITE POSITIONS.
3. THE BLADE FRAMES ARE BEING REPLACED WITH A DIFFERENT
SET OF BLADE FRAMES, SUCH AS IN A CONVERSION TO A
DIFFERENT SLICE WIDTH.
To correct the variance in slice thickness, remove the front and top covers which are
each held in place with four screws.
NOTE
A TABLE LIP IS ATTACHED BETWEEN THE TOP COVER AND THE
INFEED TABLE BY FRICTION, A SLIGHT PULL MAY BE REQUIRED
TO DISLODGE IT.
Next remove the lower screw from the holddown pivot block on each side of the
machine, also loosen the upper screw of the pivot block, but, do not remove it. When
this has been done you will be able to pivot the holddown out of the knives to allow
removal of the blade frames. Next remove the shoulder screw from the foot of the top
blade
frame, (the blade frame is connected to the rocker through a pivoting link on the
foot of the blade frame). Once disconnected the top blade frame can be removed by
sliding the frame forward out of the tracks.
WARNING
ALWAYS USE CARE WHENEVER WORKING NEAR THE CUTTING KNIVES.
