MODEL 709 MINI SUPREME BREAD SLICER
0709S20030-3
• Changing Blades:
WARNING
BLADES ARE EXTREMELY SHARP. ALWAYS
HANDLE WITH CARE.
Remove and place the Upper
blade frame on a flat surface, (see blade frame removal
section). Insert the special knife tool into the blade frame, (See Illustration). Lifting up
on the knife tool will deflect the blade mount, reducing tension on the cutting knife.
Carefully remove the cutting knife from the blade mount.
NOTE
REMOVAL OF THE LOWER BLADE FRAME IS NOT
REQUIRED TO
CHANGE ITS BLADES.
NOTE
WHEN REPLACING ALL THE BLADES, ALWAYS REMOVE THE CENTER
BLADES FIRST AND WORK TOWARDS THE ENDS. REMOVE AND INSTALL
ONE BLADE AT A TIME, NEVER REMOVE ALL THE BLADES AT ONCE
AND THEN ATTEMPT TO REPLACE THEM ALL AT ONCE.
