MODEL 709 MINI SUPREME BREAD SLICER
REVISED 3-25-98 0709S20033
RECOMMENDED SPARE PARTS
PART NUMBER
PART DESCRIPTION NO. REQ’D.
5251-8090 Bearing-Pillow Block 2
0709-0035-001 Link-Blade Frame 2
5251-3022 Bearing-2 Bolt Flange 2
5842-8525 Screw-Shoulder 3/8 X 1” 5
5251-0091 Bearing-Cam Follower 2
5915-9815 Plunger-Ball 1
0709-0038 Bushing-Flange 2
0797-0029-1 Blade-Type “A” As Req’d.
5842-8526 Screw-Shoulder 3/8 X 1-1/4 1
5749-8027 Relay-DPST 20A 240 VAC 120V Coil 1
5749-8028 Relay-DPST 20A 240 VAC 230V Coil 1
5726-1030 Holder-Fuse 1
5757-7610 Switch-Push Button 2
5757-7651 Bezel-Square Silver 2
0709-0080 Button-Square Black 1
0709-0078 Button-Square Red 1
5757-8001 Switch-Limit 2
0709-0034-XXX * Rod-Long Connecting 1
* Dependent on model of motor used -- see “Part List” which follows
OPTIONAL SPARE PARTS
NOTE
A GEARMOTOR WOULD BE CONSIDERED AN OPTIONAL SPARE
PART. GEARMOTORS SHOULD BE SELECTED BASED ON THE
MODEL FURNISHED ON YOUR MACHINE
AND THE ELECTRICS OF
YOUR MACHINE
AS INDICATED BELOW.
6310-0250 Dayton Motor (115 VAC) 1
6310-1910 Leeson Motor (115 VAC) 1
0709-0054-004 Leeson Motor (220/230 VAC) 1
To obtain Replacement parts call Oliver Products Company at 1-800-253-3893
