Oliver 709 - Electrical Panel Assembly Diagram

MODEL 709 MINI SUPREME BREAD SLICER
15/15
rev. 11/2010 0709S20044
ELECTRICAL PANEL
B-NO. PART DISCRIPTION PART NO. QTY
801 SUBPANEL 0709-0036 1
803 RELAY-DPST 20A 120/240V 5749-8027 1
807 SWITCH – SM BASIC 5757-8001 2
