Olivetti d-Copia 200D User Manual

37
4
Windows 98/Me/2000
To scan directly into an application using the Button Manager on Windows 98,
Windows Me and Windows 2000. Set the Event Manager properties to send only to
Button Manager as shown below.
1
Click the "Start" button, select "Control Panel" from "Settings",
and open "Scanners and Cameras" in start menu.
2
Select "Olivetti d-Copia 200D/201D", and click the "Properties"
button.
In Windows Me, right click "Olivetti d-Copia 200D/201D" and click
"Properties" in the menu that appears.
3
In the "Properties" screen, click the
"Events" tab.
4
Click the "Scanner events" button and
select "ScanMenu SC1" from the pull-down
menu. Select "Olivetti Button Manager P" in
"Send to this application" and click "Apply".
5
Repeat step 4 to set "ScanMenu SC2" through "ScanMenu
SC6".
Click the "Scanner events" and select "ScanMenu SC2" from the pull-down
menu. Select "Olivetti Button Manager P" in "Start this program" and click
"Apply". Do the same for each ScanMenu through "ScanMenu SC6".
When the settings have been completed, click the "OK" button to close the
screen. When the settings have been completed in Windows, start the
Button Manager. Adjust detailed settings and then scan an image from the
unit. For the procedures for starting Button Manager and adjusting settings,
see "Scan Button Destination Setting Dialog Box" (Next page).
In Windows Me, it occasionally happens that the "Scanners and
Cameras" icon does not appear immediately after installation of the MFP
driver is completed. If the icon does not appear, click "View all Control
Panel options" in the Control Panel and display the "Scanner and
Cameras" icon.
If other applications are shown,
deselect the checkboxes for the other
applications and leave only the Button
Manager checkbox selected.
Olivetti d-Copia 200D/201D
Olivetti d-Copia 200D/201D
Olivetti Button Manager P
Olivetti d-Copia 200D/201D
Olivetti d-Copia 200D/201D
Olivetti Button Manager P

Olivetti d-Copia 200D Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9.6 s
Print speed (black, normal quality, A4/US Letter)	15 ppm
Printing colors	Black
Scanner type	Flatbed scanner
Grayscale levels	256
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	20 cpm
Total input capacity	300 sheets
Internal memory	16 MB
Dimensions (WxDxH)	518 x 445 x 299 mm
All-in-one functions	Copy, Scan
Standard media sizes	A4
Supported media weight(s)	56/128 g/m²
Color all-in-one functions	scan, n
Compatible operating systems	Windows 98/Me/2000/XP/Vista
USB port	Yes
Standard interfaces	USB 2.0
Market positioning	Home & office

Weight and Dimensions

Weight	17800 g
