Olivetti d-Copia 200D User Manual

3
1
2
4
3
5
6
8
7
9
1 INTRODUCTION
USING THE MANUALS ................. 4
PART NAMES ................................ 5
OPERATION PANEL...................... 6
2 SETTING UP THE UNIT
SETUP PROCEDURE ................... 7
CHECKING PACKED
COMPONENTS AND
ACCESSORIES ............................. 8
PREPARING THE UNIT FOR
INSTALLATION .............................. 8
INSTALLING THE
TD CARTRIDGE .......................... 10
CONNECTING THE POWER CORD.. 12
3 LOADING PAPER
PAPER ......................................... 14
LOADING THE PAPER TRAY ..... 15
BYPASS FEED
(including special paper).............. 17
4 INSTALLING THE SOFTWARE
SOFTWARE................................. 19
BEFORE INSTALLATION ............ 20
INSTALLING THE SOFTWARE... 21
INDICATORS ON THE
OPERATION PANEL.................... 33
USING THE PRINTER MODE..... 34
USING THE SCANNER MODE... 36
HOW TO USE THE ONLINE
MANUAL ...................................... 45
5 MAKING COPIES
COPY FLOW ............................... 46
ORIGINAL PLACEMENT............. 47
SET THE COPY QUANTITY ....... 49
EXPOSURE ADJUSTMENT/
PHOTO COPYING....................... 49
REDUCTION/ENLARGEMENT/
ZOOM .......................................... 51
SELECTING THE PAPER TRAY .... 51
6 SPECIAL FUNCTIONS
TWO SIDED COPYING ...............52
DESCRIPTION OF OTHER
SPECIAL FUNCTIONS................54
TONER SAVE MODE ..................54
USER PROGRAMS .....................55
DISPLAYING TOTAL NUMBER
OF COPIES .................................56
7 MAINTENANCE
TONER/DEVELOPER CARTRIDGE
REPLACEMENT ..........................57
DRUM CARTRIDGE
REPLACEMENT ..........................58
CLEANING THE UNIT .................60
8 TROUBLESHOOTING THE UNIT
TROUBLESHOOTING .................62
STATUS INDICATORS .................63
MISFEED REMOVAL...................64
IF A PAPER MISFEED OCCURS
IN THE MAIN UNIT WHILE
USING THE SPF (d-Copia 201D) 69
9 APPENDIX
SPECIFICATIONS .......................70
ABOUT SUPPLIES AND
OPTIONS.....................................72
MOVING AND STORING
THE UNIT ....................................73
INDEX ..........................................74
CONTENTS

Olivetti d-Copia 200D Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9.6 s
Print speed (black, normal quality, A4/US Letter)	15 ppm
Printing colors	Black
Scanner type	Flatbed scanner
Grayscale levels	256
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	20 cpm
Total input capacity	300 sheets
Internal memory	16 MB
Dimensions (WxDxH)	518 x 445 x 299 mm
All-in-one functions	Copy, Scan
Standard media sizes	A4
Supported media weight(s)	56/128 g/m²
Color all-in-one functions	scan, n
Compatible operating systems	Windows 98/Me/2000/XP/Vista
USB port	Yes
Standard interfaces	USB 2.0
Market positioning	Home & office

Weight and Dimensions

Weight	17800 g
