Name: Olivetti d-Copia 4003MF
Brand: Olivetti
Rating: 4 (1 reviews)

Sectional Construction285

1-5-1 Precautions for assembly and disassembly285
1-5-2 Paper feed / conveying section287
1-5-3 Optical section298
- (1) Image scanner section298
  - (1-1) Detaching and refitting the exposure lamp300
  - (1-2) Detaching and refitting the image scanner unit304
- (2) Laser scanner section307
  - (2-1) Detaching and refitting the laser scanner unit309
1-5-4 Developer section312
- (1) Develolper unit312
  - (1-1) Detaching and refitting the developer unit314
1-5-5 Drum section316
- (1) Chager roller unit316
  - (1-1) Detaching and refitting the drum unit318
  - (1-2) Detaching and refitting the chager unit318
- (2) Cleaning unit319
1-5-6 [Transfer/Separation section320
- (1) Transfer/Separation320
  - (1-1) Detaching and refitting the transfer roller322
  - (1-2) Detaching and refitting the separation needle holder323
1-5-7 Fuser and eject/feedshift section324
- (1) 50/60 ppm model324
- (2) 40 ppm model326
  - (2-1) Detaching and refitting the fuser unit328
1-5-8 Eject section332
- (1) 50/60 ppm model332
- (2) 40 ppm model334
  - (2-1) Detaching and refitting the eject unit336
1-5-9 Duplex conveying section346
- (1) Duplex conveying unit346
  - (1-1) Detaching and refitting the duplex conveying unit348
1-5-10 Document processer356
- (1) Original feed section356
  - (1-1) Detaching and refitting DP paper feed roller or DP pickup pulley358
  - (1-2) Detaching and refitting the DP separation pad360
- (2) Original conveying section and switchback/eject section361
1-5-11 Covers367
1-5-12 Othes378

Electrical Parts Layout385

Operation of the PWBs397

Appendixes457

2-3-1 Appendixes457

Installation Guide484

PF-320 (Paper Feeder)484

Brand	Olivetti
Model	d-Copia 4003MF
Category	Copier
Language	English

Olivetti d-Copia 4003MF User Manual
