Olivetti d-Copia 4003MF User Manual

2-2-53
(3) Connector lists
Connector Pin Signal I/O Voltage Description
YC2
1 GND - - Ground
Connected to
the LCD
2 R0 O 0/3.3 V DC LCD Control signal
3 R1 O 0/3.3 V DC LCD Control signal
4 R2 O 0/3.3 V DC LCD Control signal
5 R3 O 0/3.3 V DC LCD Control signal
6 R4 O 0/3.3 V DC LCD Control signal
7 R5 O 0/3.3 V DC LCD Control signal
8 GND - - Ground
9 G0 O 0/3.3 V DC LCD Control signal
10 G1 O 0/3.3 V DC LCD Control signal
11 G2 O 0/3.3 V DC LCD Control signal
12 G3 O 0/3.3 V DC LCD Control signal
13 G4 O 0/3.3 V DC LCD Control signal
14 G5 O 0/3.3 V DC LCD Control signal
15 GND - - Ground
16 B0 O 0/3.3 V DC LCD Control signal
17 B1 O 0/3.3 V DC LCD Control signal
18 B2 O 0/3.3 V DC LCD Control signal
19 B3 O 0/3.3 V DC LCD Control signal
20 B4 O 0/3.3 V DC LCD Control signal
21 B5 O 0/3.3 V DC LCD Control signal
22 GND - - Ground
23 DCLK O 0/3.3 V DC LCD dot clock signal
24 3.3V O 3.3V DC 3.3 V DC power output
25 3.3V O 3.3V DC 3.3 V DC power output
26 3.3V O 3.3V DC 3.3 V DC power output
27 3.3V O 3.3V DC 3.3 V DC power output
28 DE O 0/3.3 V DC(pulse) LCD data enabling signal
29 HSYNC O 0/3.3 V DC(pulse) Horizontal synchronizing signal
30 VSYNC O 0/3.3 V DC(pulse) Vertical synchronizing signal
31 LED_EN O 0/3.3 V DC Backlight LED enabling signal
32 LED_PWM O 0/3.3 V DC Backlight LED control signal
33 TSC_INT - - Not used
34 I2C_SDA - - Not used
35 I2C_SCL - - Not used
