2-2-49
7. Open the rear cover.
8. Remove the lower interface cover and
the inlet cover.
Figure 2-2-60
9. Remove two screws.
10. Release the hooks by bending both-
side of the right middle cover and then
remove it by pulling and lifting up for-
ward.
Figure 2-2-61
Rear cover
Hook
Inlet cover
Lower
interface cover
Right middle cover
Screw
Hook
Screw
Service Manual
Y116540-5
