Olivetti MT-502 - Sensor Check List

Field Service Ver. 2.0 Jan. 2008 4. Sensor check
9
MT-502Adjustment / Setting
4.1.2 Sensor check list
Symbol Panel display Part/signal name
Operation characteristics/
panel display
10
PS10
Bin
Paper Passage 1 Lower transport sensor
Paper
present
Paper not
present
PS9 Paper Passage 2 Upper transport sensor
Paper
present
Paper not
present
PS11 Door (Jam) Cover open/close sensor Open Close
PS1
Bin1
Empty Paper detection sensor 1
Paper not
present
Paper
present
PS5 Full Paper full detection sensor 1 Blocked Unblocked
PS2
Bin2
Empty Paper detection sensor 2
Paper not
present
Paper
present
PS6 Full Paper full detection sensor 2 Blocked Unblocked
PS3
Bin3
Empty Paper detection sensor 3
Paper not
present
Paper
present
PS7 Full Paper full detection sensor 3 Blocked Unblocked
PS4
Bin4
Empty Paper detection sensor 4
Paper not
present
Paper
present
PS8 Full Paper full detection sensor 4 Blocked Unblocked
Y108462-9 Service Manual
