Field Service Ver. 2.0 Jan. 20087. Jam display
17
MT-502
Troubleshooting
7.3 Solution
7.3.1 Initial check items
• When a paper misfeed occurs, first perform the following initial check items.
Check Item Action
Does the paper meet product specifications? Change the paper.
Is paper curled, wavy, or damp?
Change the paper.
Instruct the user in correct paper storage.
Is a foreign object present along the paper path, or is the
paper path deformed or worn?
Clean or change the paper path.
Are the rolls/rollers dirty, deformed, or worn? Clean or change the defective roll/roller.
Are the edge guide and trailing edge stop at the correct
position to accommodate the paper?
Set as necessary.
Are the actuators found operational when checked for
correct operation?
Correct or change the defective actuator.
Y108462-9 Service Manual
