7. Jam displayField Service Ver. 2.0 Jan. 2008
16
MT-502
Troubleshooting
7.2 Sensor layout
[1] Upper transport sensor PS9
[2] Lower transport sensor PS10
[3] Transport sensor PS2
4510F4C501DA
[1]
[2]
[3]
Service Manual Y108462-9
