5. Technical Characteristics
Description
BS-468/Α Burglar alarm system
Power Supply
220-240V AC/50-60Hz
Consumption
11VA
Battery type
Sealed lead acid (Pb) battery 12V / 7Ah Max (not included)
Charger Stabilized power supply 13,8V / 400mA.
AS siren circuit
The AS output powers the external sirens and is used to charge the bat-
teries of these sirens with a rating of 13.8V / 500mA. This output continu-
ously provides power.
ES siren circuit
The ES output is used to power the internal siren and provides13.8V up to
500mA. It is activated during an alarm and is deactivated when the alarm
goes off.
Outputs P1,P2,P3
General outputs with a 13,8V 200mA rating. These outputs are activated
depending on the panel settings.
Relay Output
Relay change-over output (NC,C,NO). The voltage / current limit is
30VDC / 1A.
12V Output General output power for devices (13.8V / 500mA).
Zones
8 independed wired zones inputs with 5.6kΩ terminal resistance on each
of them.
32 wireless zones inputs with BS-479 extension card.
Maximum load
The maximum load connected to the panel (Outputs P1,P2,P3, BS-466/A,
12V etc.) must not exceed 1Α.
Degrees of cover protec-
tion
IP30
Humidity Up to 95% relative humidity
Constructional material ABS - polycarbonate
Dimensions 322 x 241 x 97 mm
Weight 1300 gr
Produced in accordance
with
EN 50131-1_Grade 2_Class II και EN 50131-6_Type A
Guarantee 2 years
