Disassembly and Reassembly ProcedureCLV-180
4-7
ISSUE1
3-4-1 Front panel U
3-4-2 Pump 260 eco U
Binder
(Cord holder)
Core holder 180
2 screws
Core
Binder
180 FP chassis
180 shielding plate
4 screws
FP sheet
5 screws
Gasket F 260
F panel 180 U
6 screws
UPCL18ZZ
(LED Board)
1 screw
Switch collar LL
Switch spring
Main switch
4 screws
Valve U
Upper P case
Pump U
P packing
Pump
2 screw
Pump board eco
Rubber foot
Pump base
Tubes
