Olympus CX23 User Manual

6
Adjusting the diopter ...........................................................................................................................................................................11
7
Switching the objectives ..................................................................................................................................................................12
8
Using the 100X oil immersion objective ............................................................................................................................13
5 Useful Information ..........................................................................................................................14
6 Troubleshooting ..............................................................................................................................16
7 Specifications .....................................................................................................................................18
8 Optical characteristics ...............................................................................................................19
9 Assembly ................................................................................................................................................20
10 Optional accessories ...............................................................................................................21
10-1 System diagram of optional accessories .........................................................................................21
10-2 Installation and operation of optional accessories ...................................................................21
1
Filter holder CH2-FH and darkfield ring CH2-DS ........................................................................................................21
2
Eyepieces WHSZ15X-H .....................................................................................................................................................................22
3
Mounting the eyepiece micrometer (optional) .............................................................................................................22
4
Reflection mirror CH20-MM ...........................................................................................................................................................23
5
Storing in wooden case (optional) ..........................................................................................................................................23
Proper selection of the power supply cord ..............................................................................................................................24

Olympus CX23 Specifications

General

Type	Biological Microscope
Observation Method	Brightfield
Objective Lenses	4x, 10x, 40x, 100x (oil immersion)
Stage	Mechanical Stage
Illumination	LED
Condenser	Abbe condenser (NA 1.25)
Optical System	UIS2 (Universal Infinity System)
Magnification	40x to 1000x
Power Supply	AC 100-240V, 50/60Hz
Eyepiece	10x (FN 20)
Focusing	Coaxial coarse and fine focusing
