5
CX23
} Refer to the drawing below and make sure that all necessary components are included in the product you
purchased.
1 Standard combination
Objectives
·
Optional accessories
· Filter Holder
CH2-FH
· Eyepieces
WHSZ15X-H
· Reflection mirror
CH20-MM
· Darkfield ring
CH2-DS
AC adapter
Microscope frame
Power cord
· 4X, 10X, 40X, 100X
(CX23LEDRFS1)
· 4X, 10X, 40X
(CX23LEDRFS2)
Binocular observation
tube
Eyepieces
(Fixed at 10X)
Revolving nosepiece
Condenser
Stage
· Objective 100X
· Wooden case : CH20-WB2
·
Eyepiece micrometer : diameter 24 mm, pitch 1.5 mm
The objectives have been screwed in tightly to prevent them from being loosened during
transportation.
To remove an objective, turn it counterclockwise while holding it with a rubber sheet, etc., so that your
fingers don’t slip.
CAUTION
