27
CX33
9 Assembly
Specimen holder
CX3-SHP/CX3-HLDT
(Option)
Darkfield ring slit
CH2-DS
(Option)
Filter
Diameter: 45mm
(Option)
Filter
Diameter: 32.5mm
(Option)
Filter holder CH2-FH
(Option)
Microscope
CX33RTFS2
For darkfield observation
9-1 Assembly diagram
The number in the following diagram indicates the order to attach each unit.
The detail assembly procedures are described on and after next page.
1
2
2
4
6
6
7
7
5
8
3
Standard 10X eyepiece
(detachable)
Eyepiece
WHSZ15X-H
(Option)
Camera adapter
U-TV1XC
(Option)
Camera
DP22 / DP27
(Option)
Eyepiece micrometer
(Option)
Power cord
Objective
CXPL20X
CXPL100XO
(Option)
AC adapter
9
Allen wrench
holder
9
10
