Attaching the filter holder CH2-FH and darkfield ring slit CH2-DS
a
If necessary, insert the filter
a
in the filter holder (window lens) at the base
of the microscope frame.
One to several filters of 45mm in diameter can be inserted in stack.
(Insertable thickness: up to 1.6mm)
If it is difficult to attach the filter due to the narrow space,
rotate the coarse focusing knob to raise the stage.
TIP
NOTE
8
Attaching the filter of 45mm in diameter
For details, see page 17.
