29
PCIe extension box 165(W) x 203(D) x 28(H) mm (excluding projections), approx. 800 grams
Camera head 112( ) x 87.8(H) mm (excluding projections), approx. 1,150 grams
PCIe interface board 181(W) x 121(D) x 21.6(H) mm (excluding projections), approx. 200 grams
Interface cable Approx. 2.7 meters
External trigger cable Approx. 0.2 meter
Dimensions & weight <DP72>
<PCIe Extension Unit>
ExpressCard 34(W) x 100(D) x 11(H) mm (excluding projections), approx. 24.5 grams
AC adapter 60(W) x 110(D) x 34(H) mm (excluding projections), approx. 250 grams
Cord length: Approx. 1.0 meter.
PCIe x1 cable Approx. 1.7 meter
Operating environment
* These items can be set from the DP2-BSW. (Ver 2.1 or later)
** The values of these items are variable depending on the exposure time setting and the computer operating situations.
Item Specifications
· Indoor use.
· Altitude: Max. 2000 meters
· Ambient temperature: 10° to 35°C (50° to 95° F)
· Relative humidity: 20% to 85% (without condensation)
· Supply voltage fluctuations; ±10%.
· Pollution degree: 2 (in accordance with IEC60664)
· Installation/Overvoltage category: II (in accordance with IEC60664)
