2
EN
Camera
Hot shoe gP. 78
Mode dial gP. 4
Self-timer/
Remote control lamp/
Remote control receiver
gP. 60
Mirror gP. 35
Lens release button
gP. 13
Lens attachment mark
gP. 13
Mount
(Attach the lens after removing the
body cap from the camera to
prevent dust and dirt from entering
the camera body.)
ISO button
gP. 50
Lens lock pin
F (Exposure
compensation)
button gP. 47
Built-in flash gP. 76
# (Flash) button gP. 76
w (Flash intensity control) button gP. 76
Strap eyelet gP. 11
Sub dial (k)
gP. 20
Shutter button
gP. 17, 35, 58
Strap eyelet
gP. 11
DC-IN jack gP. 128
Connector cover
External flash connector
gP. 81
LIGHT button gP. 15
WB (White balance) button
gP. 66
Control panel gP. 7
White balance sensor gP. 67
Preview button
gP. 45
