Configuration of Visualization Modes
Setting Parameters according to User Preferences
4
3
2
5
7
8
6
1
Marker
Flags
Subimage
Different parameters such as the visualization of flags, subimage position and marker display can be configured
according to user preferences.
Configurations for Normal Mode
· Length and thickness of the flags
1 2
· Subimage position and size
3 4
· Marker thickness in subimage
5
· Maximum numberof markers shown (up to 10) in the subimage
6
Configurations for Target Mode
· Marker thickness
7
· Maximum number(up to 10) of markers shown
6
· Duration of Target Mode after transitioning to it
8
(e.g., setting it to unlimited).
Normal Mode Target Mode
