Olympus EVOLT E-410 - Main Specifications

122 EN
Interchangeable lenses
10
• Use the hood when shooting a backlit subject.
• For 17.5-45 mm lens, the lens hood is not provided.
 Main Specifications
Can be used with the optional EX-25 extension tube under the following conditions.
The focus adjustment when EX-25 is used will be MF.
 Attaching the hood  Storing the hood
Items 17.5-45 mm 14-42 mm 40-150 mm
Mount FOUR THIRDS mount
Focal distance 17.5 - 45 mm 14 - 42 mm 40 - 150 mm
Max. aperture f3.5 - 5.6 f3.5 - 5.6 f4 - 5.6
Image angle 63 o - 27 o 75 o - 29 o 30 o - 8.2 o
Lens configuration
7 groups, 7 lenses 8 groups, 10 lenses 9 groups, 12 lenses
Multilayer film coating (partially single layered)
Iris control f3.5 - 22 f3.5 - 22 f4 - 22
Shooting range 0.28 m - ) 0.25 m - ) 0.9 m - )
Focus adjustment AF/MF switching
Weight (excluding hood and cap) 210 g 190 g 220 g
Dimensions
(Max. diameter × overall length)
l71 × 70 mm l65.5 × 61 mm l65.5 × 72 mm
Lens hood mount k Bayonet
Filter mount thread diameter 52 mm 58 mm
Lens, focal distance Shooting range
Magnification
(): Calculated based on 35 mm film camera
17.5-45 mm
17.5 mm
Shooting is not possible since subjects cannot be brought into focus at
this focal length.
28 mm 15.1 cm - 15.9 cm 0.89 - 1.16× (1.78 - 2.32×)
45 mm 18.4 cm - 22.4 cm 0.57 - 0.91× (1.14 - 1.82×)
14-42 mm
14 mm
Shooting is not possible since subjects cannot be brought into focus at
this focal length.
25 mm 13.3 cm 1.02× (2.04×)
42 mm 16.2 cm - 17.3 cm 0.61 - 0.69× (1.22 - 1.38×)
40-150 mm
40 mm 19.0 cm - 20.4 cm 0.61 - 0.70× (1.22 - 1.40×)
80 mm 28.0 cm - 40.6 cm 0.32 - 0.48× (0.64 - 0.96×)
150 mm 48.0 cm - 118.8 cm 0.17 - 0.39× (0.34 - 0.78×)
