Olympus IPLEX UltraLite - Distal End;Optical Adapter Nomenclature

10
2 Nomenclature
2.2 Distal end/optical adapter nomenclature
* For information about the product abbreviation, see the optical adapter instruction manual.
No. Name No. Name
1 Optical adapter positioning cut surface 7 Nut
2 First screw thread 8 O-ring
3 Second screw thread 9 Illumination
4 Connecting screw thread 10 Index
5 Objective lens 11 Product abbreviation*
6 Electrode 12 Positioning pin
123
5
6
z
z
Distal end
778 85 59 9
10
11
10
11
z
Optical adapter
1
8
4
5
6
z
z
Distal end
z
Optical adapter
7
7
5
5
9
9
10
10
11
11
4-mm type 6-mm type
z
Optical adapter internal view
z
Optical adapter internal view
12
6
4
12
6
2
3
