5 Menu operations and functions
5.2 Using the live screen/freeze screen
Menu display and functions
The settings described in the table below can be configured using the live screen/freeze screen
menu.
*: Initial default
Available settings Menu
Title input
A title can be displayed in the live screen and in registered images. Input
can be up to 30 characters.
See "Inputting a title" (P. 29).
TITLE INPUT
White balance adjustment (Live screen only)
Specifies whether to perform white balance.
• CANCEL : Do not adjust.
• EXECUTE : Adjust.
After changing the optical adapter, capture an image of a white object, such
as a piece of paper, from a distance of 50 to 60 mm.
WHITE BALANCE
The following menu is in the "SETUP" menu.
PC USB connection
Specifies whether to establish a USB connection with a PC.
Specifying USB connection enables import of instrument images to a PC.
• CANCEL : Do not configure PC connection settings.
• EXECUTE : Configure PC connection settings.
PC
[FRZ/REC] button image type setting
Specifies the type of image that is recorded when a record operation is
performed with the [FRZ/REC] button. Long-pressing the [FRZ/REC] button
performs one of the following operations.
• STILL+MOVIE*:
Live screen :Records still image and movie.
Freeze screen :Records still image only.
• STILL ONLY:
Live screen :Records still image only.
Freeze screen :Records still image only.
REC FUNCTION
Date, title, and other information recording
Specifies date, time, title and logo and other information included on the
display should be recorded in images.
• ON : Record information.
• OFF* : Do no record information.
PRINT SCREEN
ON/OFF
