2-3 Operation Selection of the DIP Switches
}The allocated functions of the DIP switches are shown in the table below.
# Make sure the main switch is set to “
” (OFF) before setting the DIP switches. The unit detects the new settings
only when the power is switched on, making those settings effective.
}The shaded sections show factory settings (all set at OFF).
Regarding the RS232C Cable
# Be sure to use a commercially available RS232C straight cable. (Use of other cables may cause malfunction.)
Use a D-Sub 9P (female)–D-Sub 9P (female) connector. Be sure to set the main switches of the control box and PC
to “ ” (OFF) before connecting the RS232C cable.
Setting of U-ZPCB etc.
# When combining the U-ZPCB or other focus control boards, set the following dip switches on the board to ON and
insert to the control box;
· S3-No.4
· S4-No.5
Be sure to set the main switches of the control box to “ ” (OFF) before inserting the board.
OFF
12345678
OFF
ON
OFF
OFF
OFF
OFF
OFF
ON
OFF OFF OFF OFF OFF OFF OFF OFF
DIP Switch
Switch Position
Function
Detail
SW1 (upper row)
Buzzer prohibited
Activates buzzer.
Does not activate buzzer.
Reserved for manufacturer
Initialization prohibited
when power is switched on
All fixed at OFF.
Reserved for manufacturer
SW2 (lower row)
Does not initialize.
Initializes.
OFF
Reserved for manufacturer
Fixed at OFF.
Fixed at OFF.
