Chapter 4 Operation
21
COLPOSCOPE OCS-500
4.7 Eyepiece shade height adjustment
For surgeons wearing eyeglasses, it is recommended that the eyepiece shade
be folded down for ease of observation (see Figure 4.14).
Figure 4.14
4.8 Focusing
Rotate the focusing knob to adjust the focus of the observed area (see Figure
4.15).
Figure 4.15
Eyepiece
shade
Focusing
knob
