System Setup
5
5.1 Items That can be Set on Menus
40
NOTE
If you press “b” and “B” simultaneously during a setup,
the setting value will become the factory default value.
ZOOM
SETUP
LAY SETUP Go to the LAYOUT SETUP menu.
ZOOM PART “OFF” “PART” “ALL” Set the print layout. “OFF”
H START (ZM) “500” to “700” Set the image capture start position.
(Horizontal direction)
“544”
V START (ZM) “0” to “2000” Set the image capture start position.
(Vertical direction)
“0”
H WIDTH (ZM) “600” to “1400” Set the image capture width.
(Horizontal direction)
“1184”
V WIDTH (ZM) “600” to “1000” Set the image capture width.
(Vertical direction)
“888”
SYSTEM
SETUP
PRN SETUP Go to the PRINTER SETUP menu.
LCD-CNTR. “0” to “14” Set the background contrast of the LCD panel. “7”
BAUDRATE “1200” “2400” “4800”
“9600”
Set the RS-232C communication rate. “4800”
BEEP “OFF” “ON” Set whether the buzzer beep is generated
when a front panel button is pressed.
“ON”
IRE “100” “110” “120”
“130”
Set the contrast of the input video signal. “100”
SAVE USER “1” “2” “3” Save the setups in memory. “1”
USER NAME 16 characters Register the user name of the setup saved
using “SAVE USER.”
—
FUNCTION
SETUP
PRN SETUP Go to the PRINTER SETUP menu.
AUTO LIVE “OFF” “ON” Switch the output image at capturing between
the memory and source image.
“OFF”
RM2 FUNC (See Table 5.6.) Set the function of the REMOTE2 connector. “C&PRINT”
CLEAR “ALL” “PAGE”
“PART” “OFF”
Set the operation activated with the CLEAR
button on the front panel.
“ALL”
STORE IMAGE “STORE” “RESTOR.” Set the operation of the internal memory. “RESTOR.”
COLOR
BALANCE
BASIC SETUP
PRN SETUP
Go to the BASIC SETUP menu.
Go to the PRINTER SETUP menu.
BAL X “1” to “99” Set the reference range for color tone
adjustment in printed picture.
“43”
BAL Y “1” to “99” Set the reference range for color tone
adjustment in printed picture.
“50”
BAL STEP “1” to “20” Set the adjustment steps for color tone
adjustment in printed picture.
“5”
TEST PRINT Start test print.
Table 5.1
Menu Item Setting values Details Factory default
To Next Page
